Yamaha EMX5014C Powered Mixer


Out of stock


The Yamaha EMX5014C Powered Mixer is an all in one powered mixer that provides you with a high powered mixer, power amplifiers, digital effects and graphic equalizers in a single versatile unit. The Mixer is rack mountable and very easy to take with you where ever you may need it.

Console Controllability and Versatility

With the many features and control functions provided by the Yamaha EMX5014C Powered Mixer, console style is the only way to go. It’s still compact enough to be placed in the stage area and controlled by the performers – especially if rack mounted – but its console configuration also makes it an ideal choice for front-of-house type operation by a sound engineer. Linear faders are another advantage of the console layout, providing precise level control as well as graphic representation of relative channel levels.

Expanded EQ Capability

Like the other EMX-series mixers, the Yamaha EMX5014C Powered Mixer features 3-band EQ on all input channels.The 5014C goes a step further with six mono channels and mid-frequency sweep controls. The mid EQ center frequency can be continuously swept from 250 Hz through 5 kHz so you can precisely pinpoint frequencies in the critical midrange that require compensation or enhancement, providing significantly greater enhanced tailoring potential. The stereo graphic equalizer has also been expanded with 9 bands that can be used for more effective room voicing or feedback control.

One-knob Compression on Mono Channels

Built-in channel dynamics is normally a feature reserved for much larger (and more expensive) mixers. But in the Yamaha EMX5014C Powered Mixer you get compressors on all six monaural mic/line channels. Judicious application of compression can help to make vocals ride the mix better, give you that smooth compressed guitar sound, deliver more punchy bass, and generally refine your mixes in a multitude of ways. Yamahas unique one-knob compressors are simple to use, too. Theres no need to juggle multiple attack, threshold, makeup gain, and other controls, just set the COMP control to the amount of compression you need.

Yamaha EMX5014C Powered Mixer Feedback Channel Locating (FCL) System

FCL System indicator LEDs at the top of each channel light if the corresponding channel goes into feedback. So if and when feedback occurs you ll be able to locate the channel(s) in which it is occurring immediately and rectify the problem without delay.

Yamaha EMX5014C Powered Mixer Versatile 14-Input Configuration

The Yamaha EMX5014C Powered Mixer has a total of 14 input channels – six for monaural microphone or line input, plus four stereo pairs.

Yamaha EMX5014C Powered Mixer SPX Digital Effects

You can dial up a selection of 16 top-quality Yamaha SPX effects, including reverb, echo, chorus, flanger, phaser, and even distortion. Yamaha SPX digital effects are widely recognized as being some of the finest available, and the effects provided in the EMX mixers live up to that reputation.

Yamaha EMX5014C Powered Mixer Feedback Channel Locating (FCL) System

  • Gain controls and 26-dB pad switches allow optimum level matching with just about any source.
  • 80-Hz high pass filters for elimination of unwanted lowfrequency noise and rumble.
  • Channel ON switches let you switch individual channels into or out of the mix.
  • Pan control adjusts the position of mono channel signals in the stereo sound field, while balance controls on stereo channels control the balance of the stereo image.
  • High-quality linear faders individually adjust the level of each channel.
  • PFL (pre-fader listen) switches allow isolated monitoring of individual channels.
  • All input channels feature signal and peak indicators for visual signal monitoring.
  • Linear AUX 1, AUX 2, and EFFECT RTN faders with AFL (after-fader listen) monitor switches.
  • Stereo master fader with both PFL and AFL monitor switches.
  • Limiter indicators tell you when the internal limiter circuitry has been activated due to power amplifier overload.
  • Power Amp mode selector allows two channel power amplifier to be quickly configured for Main + Main, Mono + Aux 1, or Aux 1 + Aux 2 operation.
  • Power amplifier output selector allows selection of 500, 200, or 75 watt output per channel.
  • Stand-by switch instantly mutes all mono inputs.
  • Precise 12-segment stereo level meter.
  • Phones jack with independent level control.
  • High-quality SPEAKON speaker connectors for fast, reliable connection. Phone jack connectors are also provided.

Get your Yamaha EMX5014C Powered Mixer now.

Additional information

Weight 14 kg
Dimensions 60 × 54 × 28 cm
