Yamaha DXR12 MKII Active PA Speaker

679.00

Out of stock

Description

Yamaha DXR12 MKII Active PA Speaker

The Yamaha DXR12 MKII Active PA Speaker is 1100 Watts of audio fidelity. Picking up where the initial DXR series left off, the mkII goes even further. Packed with innovative DSP and features, from a built-in mixer to an intelligent multi-band compressor. The DXR12mkII does everything it can to ensure you’re always sounding your best. Topped off with a versatile range of mounting options. And a durable yet compact ABS enclosure. The DXR12mkII is a PA speaker that is as powerful as it is precise.

Raw power

With a 1100 Watt Class-D amplified design, the Yamaha DXR12mkII 12” Active PA Speaker is powerful enough for any live environment. An intelligent multi-band compressor calculates level-based EQ adjustments. Ensuring consistent clarity. And with the ability to handle obscene sound pressure levels, you can be confident that the DXR12mkII won’t be bested.

Fine-tuned

The DXR12mkII is clever enough to give you the best sound possible. Yamaha’s innovative FIR-X Tuning intelligently manages frequencies. Combatting phase cancellation, ensuring clarity, and with exceptionally smooth crossover. Meaning you’ll always sound exceptional.

Mixed in

Getting a great sound couldn’t be easier, thanks to the integrated 3-channel mixer. Each channel has its own volume control to balance your sources. Once you’ve got a great balance, the sound output can be adjusted to different spaces and applications, with easy contouring preset switches.

Versatile design

You can use the DXR12mkII in a variety of configurations. For floor monitoring applications, a 50° angle is integrated into the cabinet design for easy placement. Two 35 mm speaker pole mounts let you mount the speaker at an angle of either 0°, or 7°.

Yamaha DXR12 MKII Active PA Speaker Features:

  • Register your product with Yamaha and receive an extended 7 year warranty
  • D-contour intelligent multi-band compressor optimises your sound
  • FIR-X tuning crossover stops phase issues in the mid-range
  • 50° monitor angle when laid on the side
  • Two 35 mm speaker pole mounts at 0° and 7°
  • Super efficient class D amplification with 700 watts continuous output
  • Integrated 3 channel mixer lets you easily balance input sources
  • Easy to use presets for different rooms and PA configurations

Yamaha DXR12 MKII Active PA Speaker Specifications:

General

  • System type: 2 way, bi-amped, bass reflex powered speaker
  • Frequency range (-10 dB): 52 Hz – 20 kHz
  • Coverage angle: H 90° x V 60° constant directivity horn
  • Crossover type: FIR-X tuning (linear phase FIR filter)
  • Max SPL (peak): 134 dB SPL

Transducers

  • Low frequency:
    • Diameter: 12” cone
    • Voice coil: 2.5”
    • Magnet: Ferrite
  • High frequency:
    • Voice coil: 1.75”
    • Diaphragm: PET
    • Type: 1” throat compression driver
    • Magnet: Neodymium

Enclosure

  • Material, finish, colour: ABS, matte black
  • Floor monitor angle: 50° Symmetrical
  • Dimensions (WxHxD): 362 x 601 x 350 mm
  • Net weight: 18.6 kg
  • Pole socket: 35 mm x 2 (0° or 7°)
  • Rigging points: Top x 2, Rear x 1, fits for M10 eyebolts

Amplifier

  • Amplifier type: Class-D
  • Dynamic power rating: 1100 watts
  • Continuous power rating: 700 watts
  • Cooling: fan cooling, 4 speeds
  • AD/DA: 24 bit, 48 kHz
  • Signal processing: 48 bit
  • HPF/LPF: off, 100, 120 Hz 24 dB/octave
  • DSP presets: D-contour, FOH/main, monitor, off
  • Input connectors: 1 x XLR/1/4” jack combo, 2 x 1/4” jack, 2 x RCA pins
  • Output connectors: 2 x XLR
  • Idle power consumption: 35 watts

Additional information

Weight 24 kg
Dimensions 78 × 45 × 34 cm
